The Forcemech UltraLite G10 is built for people who want the freedom of a power wheelchair without the bulk and weight of a traditional power chair. Weighing just 25.8 lbs without the battery, the UltraLite G10 is exceptionally easy to transport, fold and take along for everyday outings and travel.
Despite its ultra-light design, the G10 supports users up to 300 lbs. That's an impressive combination for someone looking for a lightweight folding electric wheelchair that doesn't sacrifice useful capacity.
This is the part I'd sell harder.
A portable power wheelchair isn't very portable if it's too heavy to conveniently get into a vehicle. The UltraLite G10 folds to approximately 29" × 12" × 28", making it much easier to store and transport than a conventional power wheelchair. The battery itself weighs approximately 2 lbs.
For shopping trips, restaurants, family outings, vacations or simply getting around away from home, the G10 is designed around portability first.
Why we like the UltraLite G10:
| Overall dimensions (LWH) | 36" x 24" x 35" | Folded dimensions (LWH) | 29" x 12" x 28" |
| Total weight (Without Battery) | 25.8lbs | Battery weight | 2lbs |
| Pivot width | 44" | Mass Tolerance | ± 4.4lbs |
| Reversing width | 59" | Turning radius | 28" |
| Ground clearance | 1.25" | Required width of angled corridor | 39" |
| Required doorway entry depth | 62" | Required corridor width for side opening | 35" |
| Static stability | 9° | Driving distance | 10miles |
| Dynamic stability uphill | 6° | Climbing ability | 3° |
| Maximum Climbing Degree | 10° | Max over the obstacle height | 1" |
| Maximum speed forward | 4mph | Minimum braking distance from max speed | ≤ 39" |
| Seat plane angle | 4° | Effective seat depth | 16.5" |
| Seat width | 18" | Effective seat width | 20" |
| Seat surface height at front edge | 17.3" | Backrest angle | 8° |
| Backrest height | 17.5" | Back support height / Backrest height | 16.4" |
| Distance from Footrest to Seat | 15.3" | Distance from Footrest to Surface | 3" |
| Footrest length | 4.5" | Footrest to leg angle | 97° |
| Leg to seat surface angle | 114° | Armrest height | 9.5" |
| Front location of armrest structure | 14" | Armrest Length | 15" |
| Armrest Width | 2" | Armrest Angle | 2.5° |
| Audible noise | ≤ 65dB (A-weighted) | The forces necessary to operate the control devices | Push-button 2N, Rockers 5N |
| Motor Model | 24V 200W | Lithium Battery Specification | 24V / 10Ah |
| Maximum Output Current of Controller | 35A | Maximum Output Current of Charger | 2A |
| Diameter of movable wheels / Castor wheel diameter | 6.5" | Diameter of fixed wheels / Propelling wheel diameter | 11" |
| Linear Tolerance | ± 2° | Angular Tolerance | ± 2° |
